How tight should vinyl siding be nailed?

Allow approximately 1/32” (0.8mm) clearance (the thickness of a dime) between the fastener head and the vinyl. Tight nailing, screwing, or stapling will cause the vinyl siding to buckle with changes in temperature (Fig. 16).

What happens if you nail vinyl siding too tight?

If the siding is nailed onto the house too tightly, it will begin to warp or distort. Unfortunately, the buckling won't correct itself and will have to be replaced. If you're having siding installed, grab a piece of it and make sure you can move it about a half an inch side to side.

How close should you nail vinyl siding?

Space the Nails Properly

Siding panels should be nailed 12 inches to 16 inches on-center.

When nailing vinyl siding nails should be?

The minimum nail size should be 1-1/2". Example: If you're applying siding over 1/2" structural sheathing, use a nail at least 1-1/2" long (1/2" sheathing + 3/4" stud penetration + nailing hem thickness + minimum 1/16" between nailing hem and fastener head).

Why is vinyl siding never nailed tightly?

Vinyl siding tends to expand and contract considerably with temperature changes. For this reason, manufacturers design it to hang loosely on the nails rather than to be tightly nailed like wood siding. The problem should be easy to diagnose.

Kaycan Vinyl Siding Installation Tips: Nailing

What would cause vinyl siding to buckle?

Usually, the siding was nailed too tightly. Vinyl siding expands significantly as it's heated. That's why it has oval-shaped nailing slots that allow it to slide back and forth under the nailhead. Nail it too tightly and you prevent this movement—and cause buckling.

How long should siding nails be?

Most contractors agree that nails used in siding projects should measure at least 1 ½ inches long—or up to 2 ½ inches if you're installing backerboard with the siding.

Does vinyl siding need to be nailed into studs?

NOTE: Vinyl siding must be applied over a rigid sheathing that provides a smooth, flat surface or an underlayment (such as wood, wood composition, rigid foam or fiber sheathing) that is no more than 1" thick. Vinyl siding cannot be applied directly to studs.

What is the maximum spacing of the nailing on a vinyl siding panel?

Space the fasteners a maximum of 16” (406mm) apart for horizontal siding panels, every 12” (305mm) for vertical siding panels, and every 8” to 12” (203mm to 305mm) for accessories. These distances may be increased if the manufacturer permits greater spacing based on wind load testing.

Why does my siding keep falling off?

If your siding is continually falling off, it may be that you don't have the right siding for your climate. Wind and water are the two most problematic elements, so make sure your siding is up to par to keep these from damaging it.

Does vinyl siding expand and contract?

A standard piece of vinyl siding and trim may expand and contract up to 1/2 an inch in extreme temperatures, between the coldest winter day and the hottest summer day. Knowing how much your vinyl siding will expand is essential in installing your siding.

Can siding nails be too long?

If the contractor nails the siding too tightly, it will restrict the movement and the siding is likely to crack. As a general rule, contractors should use a clearance of 1/32 inch between the siding and nail head.

How many nails do I need for vinyl siding?

It's best to estimate the square footage of the vinyl siding to determine approximately how many nails you need. You'll also want to consider the space for the nails. On average, you'll need to install about 115 nails per square [or 100 square feet].

What's the best nails to use for vinyl siding?

What kind of nails do you use to hang vinyl siding? Use electro, or hot-dipped galvanized steel or aluminum roofing type nails with a diameter of 1/8″ and a nail head of 3/8″ or larger. The nails should penetrate 3/4″ into a solid wood base.

How do you nail vinyl siding?

Vinyl siding must be attached “loosely.” Center nails in slots to permit expansion and contraction of the siding. Drive nails straight and level to prevent distortion and buckling of panel. Start nailing vertical siding and trim pieces in the top of the uppermost slots to hold them in position.

How do I keep my vinyl siding from falling off?

While the siding if unattached and dangling, take your siding snips, or a pair of needle nose pliers will also do the trick. With your snips grab ahold of the bottom track and give it a twist. Do this every couple of feet. For some added insurance, squeeze some caulking into the track before clipping it back together.

Does vinyl siding Bend?

Causes & Cures for Damaged Vinyl Siding: Bent, Buckled, Rippled or Sagging Vinyl Siding. Surface distortion of vinyl siding has been recognized as a problem since the early 1960's when it was described as "oil canning" (Summers 1983).
